Single-Sheave Marine Open-Sided Lead Block
Product Overview
This single-sheave marine lead block is designed for lifting and pulling with wire rope or other suitable rope. Its open-sided construction allows the rope to be installed from the side, while the cast-steel sheave and solid bronze bushing provide durable and smooth operation.
Versatile Rope Handling
Suitable for lifting and pulling applications using wire rope or rope.
Open-Sided Design
The rope can be inserted from the side for faster and easier installation.
Cast-Steel Sheave
A durable cast-steel sheave supports demanding operating conditions.
Solid Bronze Bushing
The sheave is fitted with a solid bronze bushing for smooth movement and
reliable service.
Dimensions and Technical Specifications
| Item No. | Rated Load kN (t) |
Breaking Load kN (t) |
Dimensions (mm) | Net Weight (kg) |
Wire Rope Dia. (mm) |
||
|---|---|---|---|---|---|---|---|
| A | B | C | |||||
| SL-CY01-01 | 30 (3) | 90 (9) | 413 | 140 | 84 | 10 | 18–20 |
| SL-CY04-01 | 50 (5) | 150 (15) | 437 | 162 | 89 | 12 | 20–22 |
All model numbers, load ratings, dimensions and weights are reproduced from the source parameter table.
