Product Overview

The QT Drum Lifting Clamp is designed for lifting oil drums, with particular suitability for vertical drum handling. Its compact construction makes the clamp straightforward to position and operate during routine lifting work.

Manufactured from high-quality low-carbon alloy steel, the clamp combines strength and durability with stable load handling. The rated capacity is 0.2 metric tonnes.

Operating and Safety Notes

• The rated load is established by testing one clamp, and the clamp is intended to be used individually during lifting operations.
• The proof load is twice the rated load.
• Prevent the suspended drum from striking surrounding objects during lifting.
• Never exceed the rated working load.

Technical Specifications

Model	WLL (tonnes)	Jaw Opening (mm)	Weight (kg)
QT0.2	0.2	1–9	1.3

WLL: Working Load Limit.
