LH Double Girder Overhead Crane

  • Price is upon on request based on different specificaitons

  • LDA overhead crane is a compact and economical bridge crane featuring a lightweight single girder structure. It provides reliable lifting performance, easy installation, and smooth operation, making it an ideal solution for material handling in factories, workshops, and warehouses.
  • It is a tradtional overhead crane with cost effective for small or genral workshops.
LYFOOCRANE LH double girder light duty overhead crane
Light-Duty Double Girder Crane

LH Double Girder Overhead Crane

The LH double girder overhead crane is designed for light-duty material handling in workshops, assembly areas, warehouses and general industrial facilities.

It is typically configured for an A3 duty class (approximately FEM 1) and combines a double-girder bridge with a wire-rope hoist trolley for stable lifting and travel.

Wire-Rope Hoist Trolley

The crane uses a trolley-type wire-rope hoist. The trolley travels on top of the two bridge girders on four wheels, providing stable lifting and cross travel.

This top-running arrangement makes effective use of the available working space and is especially suitable for lifting capacities of 10 tonnes and above.

  • Stable lifting and trolley travel
  • Efficient use of workshop headroom
  • Suitable for warehouses and general workshops
Wire-rope hoist trolley on an LH double girder overhead crane
LH overhead crane box girder structure

Double Box Girders

Two box girders support the hoist trolley. Long travel is driven by two gearbox-and-motor assemblies, helping the crane move smoothly along the runway.

Double box girders of an LH overhead crane
End carriage and travel wheels of an LH overhead crane

End Carriages

The end carriages use 400 mm diameter travel wheels. Buffers are installed to help protect the crane at the end of its travel and reduce collision impact.

Safety Components

Overload protection component for overhead crane Wire-rope hoist safety component Overhead crane hoist safety component
Overhead crane runway rail and fixing system
Optional Parts

How to Choose the Runway Rail

The rail specification is selected according to the crane wheel load. Available rail weights include 24 kg/m, 38 kg/m and 43 kg/m, subject to the crane design.

The total rail quantity is twice the crane travel length. For example, an 80 m runway requires 160 m of rail in total—80 m on each side.

Matching fixing parts, such as pressure plates, joint bars and rubber pads, can be supplied. Rails may be fixed by welding or bolting according to the project requirements.

important

Please contact us for the cusotmized crane to get an solution for your project.
