Grade 80 Symmetrical Swivel Hoist Ring
Grade 80 symmetrical swivel hoist ring designed to align with the direction of the applied lifting force. Available in Working Load Limits from 2 to 25 tonnes.
| Item No. | Weight (kg) |
WLL (t) |
Breaking Load (t) |
A ±1 (mm) |
D ±1 (mm) |
H ±1.5 (mm) |
L ±2 (mm) |
|---|---|---|---|---|---|---|---|
| SL-R1024-2 | 0.6 | 2 | 8 | 12.5 | 35.5 | 28.5 | 164 |
| SL-R1024-3.15 | 1.5 | 3.15 | 12.6 | 15 | 42 | 34.5 | 194.5 |
| SL-R1024-5.3 | 1.75 | 5.3 | 21.2 | 18 | 50 | 43.5 | 216.5 |
| SL-R1024-8 | 4.52 | 8 | 32 | 21.5 | 61 | 56 | 289 |
| SL-R1024-17 | 13.55 | 17 | 85 | 37 | 72 | 61 | 361 |
| SL-R1024-25 | 15.95 | 25 | 25 | 43 | 80 | 68 | 378 |
