Eight-Sheave Pulley Block with Lifting Eye
This eight-sheave pulley block features an integrated lifting eye and is designed for high-capacity wire-rope lifting and pulling applications. Its eight-sheave configuration provides efficient wire-rope routing in heavy-duty lifting systems.
Product Features
- The upper attachment is manufactured from high-quality alloy steel and designed with a 3:1 safety factor.
- Available with cast-iron, cast-steel or hot-rolled steel sheaves.
- Sheave bearing options include composite wear-resistant bushings, solid bronze bushings, ball bearings and needle bearings.
- Additional working-load capacities can be manufactured to order.
Dimensions and Technical Specifications
| Item No. | WLL (t) |
Test Load (kN) |
Outside Dimensions (mm) | Wire Rope Diameter (mm) | Eye Opening R (mm) |
Weight (kg) |
||||
|---|---|---|---|---|---|---|---|---|---|---|
| H | B | Lmax | Φ | Recommended | Max. | |||||
| SL-HQD8-80 | 80 | 1040 | 1105 | 365 | 740 | 44 | 26 | 28 | 125 | 480 |
| SL-HQD8-100 | 100 | 1300 | 1210 | 365 | 880 | 44 | 26 | 28 | 133 | 700 |
| SL-HQD8-160 | 160 | 2080 | 1320 | 460 | 910 | 60 | 31 | 35 | 145 | 1150 |
| SL-HQD8-200 | 200 | 2500 | 1500 | 510 | 1100 | 46 | 34 | 36 | 187 | 1500 |
WLL = Working Load Limit. All dimensions and technical values are based on the source product data.
