Construction Electric Chain Hoist

Construction Electric Chain Hoist

The Construction Electric Chain Hoist is designed for heavy-duty lifting applications where low lifting speed, stable operation and high load capacity are required. Available in capacities from 5 to 30 tons, it provides a practical lifting solution for construction, installation and other demanding industrial applications.

Heavy-Duty Lifting Solution

Designed for controlled vertical lifting of heavy loads, this electric chain hoist combines a compact drive system with multiple load-chain falls to achieve higher lifting capacities.

Its low lifting speed provides better load control during installation and positioning operations, making it particularly suitable for construction sites and heavy equipment installation.

  • Rated capacities from 5 to 30 tons
  • Low-speed lifting for controlled load positioning
  • Multiple load-chain falls for heavy-duty lifting
  • 10 mm round-steel load chain
  • 380 V / 50 Hz standard power supply
  • Suitable for construction and industrial lifting

Technical Specifications

Specification 5T 7.5T 10T 20T 30T
Rated Capacity 5 ton 7.5 ton 10 ton 20 ton 30 ton
Test Load (Gn) 1.25 1.25 1.25 1.25 1.25
Motor Power 0.5 kW 0.5 kW 0.5 kW 0.5 kW 0.75 kW
Power Supply 380 V / 50 Hz
Lifting Speed 0.09 / 0.18 m/min 0.12 m/min 0.09 m/min 0.09 m/min 0.06 m/min
Minimum Distance Between Hooks 200 / 600 mm 660 mm 730 mm 1040 mm 1480 mm
Load Chain Falls 2 3 4 8 12
Load Chain Diameter 10 mm 10 mm 10 mm 10 mm 10 mm
Net Weight 58 kg 70 kg 95 kg 195 kg 285 kg
Gross Weight 69 kg 80 kg 108 kg 225 kg 325 kg
Packing Size (L × W × H) 56 × 40 × 40 cm 50 × 42 × 39 cm 61 × 48 × 48 cm 70 × 60 × 44 cm 95 × 81 × 53 cm
Additional Weight per 1 m Lift 4.4 kg 6.6 kg 8.8 kg 17.6 kg 25.2 kg
Note: Lifting height can be configured according to project requirements. Additional chain weight increases with lifting height as shown in the specification table.

Designed for Controlled Heavy Lifting

Unlike conventional high-speed material-handling hoists, this series is designed around slow and controlled lifting. The reduced lifting speed helps operators position heavy loads more accurately during construction and installation work.

Different load capacities use multiple chain falls to distribute the lifting load. Models are available in 5, 7.5, 10, 20 and 30 ton configurations to accommodate different project requirements.

IMAGE 02
Product / Detail Image

Product Details

IMAGE 03
Hoist Body / Motor Detail
IMAGE 04
Chain & Hook Detail

Custom Lifting Configurations

Lifting height and related chain length can be configured according to specific project requirements. Please specify the required lifting capacity, lifting height, power supply and operating conditions when requesting a quotation.
