2-Leg Wire Rope Sling Assembly

Wire Rope Sling Assembly

Model: SL-WCDH Series • For Lifting Applications
Wire Rope Sling Assembly - 2 Leg Sling

Specifications & Dimensions

Model Wire Dia. (mm) WLL 0°-90° (KN) WLL 90°-120° (KN) A×B×d (mm) Hook Type Hook WLL (T)
SL-WCDH-6 6 3.6 2.7 65×130×16 US 320A 0.75
SL-WCDH-7 7 5 3.6 65×130×16 US 320A 0.75
SL-WCDH-8 8 6.6 4.7 65×130×16 US 320A 0.75
SL-WCDH-9 9 8.4 6 65×130×16 US 320A 0.75
SL-WCDH-10 10 10.4 7.4 65×130×16 US 320A 0.75
SL-WCDH-11 11 13 9 65×130×16 US 320A 1
SL-WCDH-12 12 15 11 65×130×16 US 320A 1.5
SL-WCDH-13 13 17 12 65×130×16 US 320A 1.5
SL-WCDH-14 14 20 14 65×130×16 US 320A 1.5
SL-WCDH-16 16 26 19 80×150×20 US 320A 2
SL-WCDH-18 18 33 24 90×160×24 US 320A 3
SL-WCDH-20 20 41 30 90×160×24 US 320A 3
SL-WCDH-22 22 50 36 90×160×24 US 320A 5
SL-WCDH-24 24 59 42 100×190×28 US 320A 5
SL-WCDH-26 26 70 50 100×190×28 US 320A 5
SL-WCDH-28 28 81 58 100×190×28 US 320A 7
SL-WCDH-30 30 92 66 110×200×32 US 320A 11
SL-WCDH-32 32 106 76 110×200×32 US 320A 11
SL-WCDH-34 34 119 85 135×250×38 US 320A 11
SL-WCDH-36 36 134 96 135×250×38 US 320A 11
SL-WCDH-38 38 148 106 135×250×38 US 320A 15
SL-WCDH-40 40 165 118 135×250×38 US 320A 15
SL-WCDH-42 42 182 130 140×270×42 US 320A 15
SL-WCDH-44 44 200 143 140×270×42 US 320A 15
SL-WCDH-46 46 218 156 160×310×46 US 320A 15
SL-WCDH-48 48 237 170 160×310×46 US 320A 22
SL-WCDH-50 50 259 185 180×330×52 US 320A 22
SL-WCDH-52 52 279 200 180×330×52 US 320A 30
SL-WCDH-54 54 301 215 180×330×52 US 320A 30
SL-WCDH-56 56 323 231 180×330×52 US 320A 30
SL-WCDH-58 58 347 248 180×330×52 US 320A 30
SL-WCDH-60 60 372 266 180×330×56 US 320A 37
Wire Rope Sling Assembly • Model SL-WCDH
Capacity varies with sling angle. Refer to WLL 0°-90° and 90°-120° ratings. Hook type: US 320A with specified WLL.
⚙ Hebei Shenli Rigging Group — Wire Rope Sling Assembly 📔 Model range: SL-WCDH-6 to SL-WCDH-60
